The 855GME chipset allows the VMIVME-7807/VME-7807RC to provide enhanced features such as integrated video and Ultra ATA/100 IDE support. The VMIVME-7807/VME-7807RC are capable of executing many of today’s desktop operating systems such as Microsoft®’s Windows® XP, Windows 2000 and a wide variety of Linux® based operating systems. The standard desktop features of the VMIVME-7807/VME-7807RC are described in Chapter 2 of this manual.

The VMIVME-7740 VMEbus interface is provided by the PCI-to-VMEbus bridge built around the Tundra Semiconductor Corporation Universe II VMEbus interface chip. The Universe II provides a reliable high-performance 64-bit VMEbus-to-PCI interface in one design. The functions and programming of the Universe-based VMEbus interface are addressed in detail in a separate associated manual titled: VMIVME-7740 Tundra Universe II Based VMEbus Interface Product Manual (500-657740-001).

The VMIACC-5595 is a manageable hub designed for use with GE Fanuc Embedded Systems' VMIxxx-5565 series of reflective memory real-time networking products. The reflective memory hub automatically bypasses ports when signal loss or loss of valid synchronization mode is detected, ensuring the proper functioning of other nodes in the network. Because the optical ports use Small Form-Pluggable (SFP) transceivers, only the required ports need to be installed. The VMIACC-5595's SFP transceivers can be a combination of multimode (short-range) or single-mode (long-range) transceivers. This feature helps save costs and optimize the system in small networks. For large networks, multiple VMIACC-5595 components can be cascaded to build manageable hub arrays with up to 256 nodes. Each port regenerates the serial optical signal, eliminating issues such as insertion loss and cable attenuation. Signal regeneration also reduces jitter. An RS232 port allows you to monitor and control the reflective memory network via a simple PC serial port. Ethernet port functionality allows you to monitor and control the hub remotely via a local area network (LAN) or a web browser.

GENERAL DESCRIPTION — The VMIVME-3115 is a high throughput ,12-bit Analog Input/Output (AIO) board which provides four analog inputs, two analog outputs, and dual 8-bit bi-directional digital input/output ports for VMEbus system applications. Dual-ported data memory, on-board timers, and a program-controlled bus interrupter enables the VMIVME-3115 board to support extensive analog input and output traffic with minimum involvement of the host processor.

Reflective Memory is an optical ring-based, ultra high-speed shared memory network solution. It allows a distributed network to share real-time data at a deterministic rate, regardless of bus structures and operating systems. With more than 15 years of experience in this field, J-Squared is an original pioneer of this technology and our 5565 Reflective Memory family extends our market leadership position.

　10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C per every 305 m (1.8°F per every 1000 ft) above sea level to a maximum of 3050 m (10,000 ft); no direct sustained sunlight. Maximum rate of change is 10°C/hr (18°F/hr). The upper limit may be limited by the type and number of options installed.

10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C per every 305 m (1.8°F per every 1000 ft) above sea level to a maximum of 3050 m (10,000 ft); no direct sustained sunlight. Maximum rate of change is 10°C/hr (18°F/hr). The upper limit may be limited by the type and number of options installed.

The fault locator is an impedance measuring function giving the distance to the fault in percent, km or miles. The main advantage is the high accuracy achieved by compensating for load current and for the mutual zero-sequence effect on double circuit lines.

To achieve fast clearing of faults on the whole line, when no communication channel is available, local acceleration logic (ZCLCPLAL) can be used. This logic enables fast fault clearing during certain conditions, but naturally, it can not fully replace a communication channel.
